Bending of copper closed circular pipelines with Lubrimat®. The rolls are sprayed during the bending process. Consequently, the copper no longer sticks to the roll coils and the finished products do not have to be reworked.
Calibrating
Calibration of valve chanels with Spraymat®.
Calibration of cylindrical gears made of forged steel for automatic transmission cars. The trapezoidal section is calibrated on a hydraulic press using a mould made of hardened tool steel. The workpiece is sprayed by 6 nozzles of Lubrimat®. This has meant a considerable reduction in oil consumption and processing time.
Forming
Chipless forming with Lubrimat®
Chipless forming of tube endsmade of St37 and V4A with Lubrimat®
Chipless forming of screws with Lubrimat®
Beading of high grade steel elements in washing machine drum production, approx. 500 mm diameter. Four nozzles of a Spraymat® lubricate the forming rollers and protect them against overheating and wearing out.
Chipless forming of round blanks (aluminium polished, 1,1 mm thickness, Ø 24 mm, with Lubrimat®
Lubricating sheet stell on a hydraulic press with Pulsomat®
Punching
Punching of connecting rods. The top side and underside are sprayed. Compared with manual lubrication, the method used previously, the application of the lubricant is now much more even and the tool life greater.
Punching of rivets, buttons and eyes for the garment industry, made of various types of metals (high grade steel, steel, brass). Each band conveyor is sprayed on both sides by two nozzles of a Lubrimat®.
Punching of fixing drill holes and clearances in door furniture (St37, cold rolled, 1,500 mm long, 25 mm wide) lubricated with Pulsomat®. The cleaning of the parts prior to final coating is no longer necessary.
Shearing off
Off shearing with Pulsomat®
